Product Details
＋
Ledalite TruGroove Linear Wall Washer
Products List
| Products | Watts | Lumen | Kelvin |
| TruGroove wall, MesoOptics Lens/Solid Housing, 1500lm/4ft, 80 CRI, 3000K 2921LCKQN | 15.1 | 1500 | 3000 |
| TruGroove wall, MesoOptics Lens/Solid Housing, 1500lm/4ft, 80 CRI, 3500K 2921LBKQN | 15.1 | 1500 | 3500 |
| TruGroove wall, MesoOptics Lens/Solid Housing, 1500lm/4ft, 80 CRI, 4000K 2921LAKQN | 15.3 | 1500 | 4000 |
| TruGroove wall, MesoOptics Lens/Solid Housing, 2300lm/4ft, 80 CRI, 3000K 2921LCGQN | 23.8 | 2300 | 3000 |
| TruGroove wall, MesoOptics Lens/Solid Housing, 2300lm/4ft, 80 CRI, 3500K 2921LBGQN | 23.8 | 2300 | 3500 |
| TruGroove wall, MesoOptics Lens/Solid Housing, 2300lm/4ft, 80 CRI, 4000K 2921LAGQN | 24.1 | 2300 | 4000 |
| TruGroove wall, MesoOptics Lens/Solid Housing, 3200lm/4ft, 80 CRI, 3000K 2921LCEQN | 34.9 | 3200 | 3000 |
| TruGroove wall, MesoOptics Lens/Solid Housing, 3200lm/4ft, 80 CRI, 3500K 2921LBEQN | 34.9 | 3200 | 3500 |
| TruGroove wall, MesoOptics Lens/Solid Housing, 3200lm/4ft, 80 CRI, 4000K 2921LAEQN | 35.4 | 3200 | 4000 |
| TruGroove wall, Solid Housing/Sym. Performance Lens, 3200lm/4ft, 80 CRI, 3000K 2923LCENQ | 25.7 | 3200 | 3000 |
| TruGroove wall, Solid Housing/Sym. Performance Lens, 3200lm/4ft, 80 CRI, 3500K 2923LBENQ | 25.9 | 3200 | 3500 |
| TruGroove wall, Solid Housing/Sym. Performance Lens, 3200lm/4ft, 80 CRI, 4000K 2923LAENQ | 25.9 | 3200 | 4000 |
| TruGroove wall, Solid Housing/Sym. Performance Lens, 4800lm/4ft, 80 CRI, 3000K 2923LCCNQ | 40.7 | 4800 | 3000 |
| TruGroove wall, Solid Housing/Sym. Performance Lens, 4800lm/4ft, 80 CRI, 3500K 2923LBCNQ | 41 | 4800 | 3500 |
| TruGroove wall, Solid Housing/Sym. Performance Lens, 4800lm/4ft, 80 CRI, 4000K 2923LACNQ | 41 | 4800 | 4000 |
| TruGroove wall, Dir/Ind, MesoOptics Lens/Sym. Performance Lens, 5200lm/4ft, 80 CRI, 3000K 2926LCBQQ | 50.1 | 5200 | 3000 |
| TruGroove wall, Dir/Ind, MesoOptics Lens/Sym. Performance Lens, 5200lm/4ft, 80 CRI, 3500K 2926LBBQQ | 50 | 5200 | 3500 |
| TruGroove wall, Dir/Ind, MesoOptics Lens/Sym. Performance Lens, 5200lm/4ft, 80 CRI, 4000K 2926LABQQ | 50.5 | 5200 | 4000 |
| TruGroove wall, Dir/Ind, MesoOptics Lens/Sym. Performance Lens, 4600lm/4ft, 80 CRI, 3000K 2926LCCQQ | 45.9 | 4600 | 3000 |
| TruGroove wall, Dir/Ind, MesoOptics Lens/Sym. Performance Lens, 4600lm/4ft, 80 CRI, 3500K 2926LBCQQ | 46 | 4600 | 3500 |
| TruGroove wall, Dir/Ind, MesoOptics Lens/Sym. Performance Lens, 4600lm/4ft, 80 CRI, 4000K 2926LACQQ | 46.3 | 4600 | 4000 |
| TruGroove wall, Dir/Ind, MesoOptics Lens/Sym. Performance Lens, 3500lm/4ft, 80 CRI, 3000K 2926LCDQQ | 34.7 | 3500 | 3000 |
| TruGroove wall, Dir/Ind, MesoOptics Lens/Sym. Performance Lens, 3500lm/4ft, 80 CRI, 3500K 2926LBDQQ | 34.8 | 3500 | 3500 |
| TruGroove wall, Dir/Ind, MesoOptics Lens/Sym. Performance Lens, 3500lm/4ft, 80 CRI, 4000K 2926LADQQ | 35.1 | 3500 | 4000 |
| TruGroove wall, Ind/Dir, MesoOptics Lens/Sym. Performance Lens, 3500lm/4ft, 80 CRI, 3000K 2925LCDQQ | 28.5 | 3500 | 3000 |
| TruGroove wall, Ind/Dir, MesoOptics Lens/Sym. Performance Lens, 3500lm/4ft, 80 CRI, 3500K 2925LBDQQ | 28.5 | 3500 | 3500 |
| TruGroove wall, Ind/Dir, MesoOptics Lens/Sym. Performance Lens, 3500lm/4ft, 80 CRI, 4000K 2925LADQQ | 28.6 | 3500 | 4000 |
| TruGroove wall, Ind/Dir, MesoOptics Lens/Sym. Performance Lens, 5200lm/4ft, 80 CRI, 3000K 2925LCBQQ | 46.4 | 5200 | 3000 |
| TruGroove wall, Ind/Dir, MesoOptics Lens/Sym. Performance Lens, 5200lm/4ft, 80 CRI, 3500K 2925LBBQQ | 46.4 | 5200 | 3500 |
| TruGroove wall, Ind/Dir, MesoOptics Lens/Sym. Performance Lens, 5200lm/4ft, 80 CRI, 4000K 2925LABQQ | 46.6 | 5200 | 4000 |
| TruGroove wall, Ind/Dir, MesoOptics Lens/Sym. Performance Lens, 4600lm/4ft, 80 CRI, 3000K 2925LCCQQ | 40.8 | 4600 | 3000 |
| TruGroove wall, Ind/Dir, MesoOptics Lens/Sym. Performance Lens, 4600lm/4ft, 80 CRI, 3500K 2925LBCQQ | 40.9 | 4600 | 3500 |
| TruGroove wall, Ind/Dir, MesoOptics Lens/Sym. Performance Lens, 4600lm/4ft, 80 CRI, 4000K 2925LACQQ | 41.1 | 4600 | 4000 |
| TruGroove wall, Asym. MesoOptics Lens/Solid Housing, 1500lm/4ft, 80 CRI, 3000K 2921LCKWN | 15.2 | 1500 | 3000 |
| TruGroove wall, Asym. MesoOptics Lens/Solid Housing, 1500lm/4ft, 80 CRI, 3500K 2921LBKWN | 15.2 | 1500 | 3500 |
| TruGroove wall, Asym. MesoOptics Lens/Solid Housing, 1500lm/4ft, 80 CRI, 4000K 2921LAKWN | 15.4 | 1500 | 4000 |
| TruGroove wall, Asym. MesoOptics Lens/Solid Housing, 2300lm/4ft, 80 CRI, 3000K 2921LCGWN | 24 | 2300 | 3000 |
| TruGroove wall, Asym. MesoOptics Lens/Solid Housing, 2300lm/4ft, 80 CRI, 3500K 2921LBGWN | 24 | 2300 | 3500 |
| TruGroove wall, Asym. MesoOptics Lens/Solid Housing, 2300lm/4ft, 80 CRI, 4000K 2921LAGWN | 24.3 | 2300 | 4000 |
| TruGroove wall, Asym. MesoOptics Lens/Solid Housing, 3200lm/4ft, 80 CRI, 3000K 2921LCEWN | 35.1 | 3200 | 3000 |
| TruGroove wall, Asym. MesoOptics Lens/Solid Housing, 3200lm/4ft, 80 CRI, 3500K 2921LBEWN | 35.1 | 3200 | 3500 |
| TruGroove wall, Asym. MesoOptics Lens/Solid Housing, 3200lm/4ft, 80 CRI, 4000K 2921LAEWN | 35.6 | 3200 | 4000 |
| TruGroove wall, Solid Housing/Asym. Performance Lens, 3200lm/4ft, 80 CRI, 3000K 2923LCENW | 25.6 | 3200 | 3000 |
| TruGroove wall, Solid Housing/Asym. Performance Lens, 3200lm/4ft, 80 CRI, 3500K 2923LBENW | 25.8 | 3200 | 3500 |
| TruGroove wall, Solid Housing/Asym. Performance Lens, 3200lm/4ft, 80 CRI, 4000K 2923LAENW | 25.8 | 3200 | 4000 |
| TruGroove wall, Solid Housing/Asym. Performance Lens, 4800lm/4ft, 80 CRI, 3000K 2923LCCNW | 40.5 | 4800 | 3000 |
| TruGroove wall, Solid Housing/Asym. Performance Lens, 4800lm/4ft, 80 CRI, 3500K 2923LBCNW | 40.8 | 4800 | 3500 |
| TruGroove wall, Solid Housing/Asym. Performance Lens, 4800lm/4ft, 80 CRI, 4000K 2923LACNW | 40.8 | 4800 | 4000 |
| TruGroove wall, Dir/Ind, Asym. MesoOptics Lens/Asym. Performance Lens, 5200lm/4ft, 80 CRI, 3000K 2926LCBWW | 50.1 | 5200 | 3000 |
| TruGroove wall, Dir/Ind, Asym. MesoOptics Lens/Asym. Performance Lens, 5200lm/4ft, 80 CRI, 3500K2926LBBWW | 50 | 5200 | 3500 |
| TruGroove wall, Dir/Ind, Asym. MesoOptics Lens/Asym. Performance Lens, 5200lm/4ft, 80 CRI, 4000K2926LABWW | 50.5 | 5200 | 4000 |
| TruGroove wall, Dir/Ind, Asym. MesoOptics Lens/Asym. Performance Lens, 4600lm/4ft, 80 CRI, 3000K 2926LCCWW | 45.9 | 4600 | 3000 |
| TruGroove wall, Dir/Ind, Asym. MesoOptics Lens/Asym. Performance Lens, 4600lm/4ft, 80 CRI, 3500K 2926LBCWW | 46 | 4600 | 3500 |
| TruGroove wall, Dir/Ind, Asym. MesoOptics Lens/Asym. Performance Lens, 4600lm/4ft, 80 CRI, 4000K2926LACWW | 46.3 | 4600 | 4000 |
| TruGroove wall, Dir/Ind, Asym. MesoOptics Lens/Asym. Performance Lens, 3500lm/4ft, 80 CRI, 3000K 2926LCDWW | 34.7 | 3500 | 3000 |
| TruGroove wall, Dir/Ind, Asym. MesoOptics Lens/Asym. Performance Lens, 3500lm/4ft, 80 CRI, 3500K 2926LBDWW | 34.8 | 3500 | 3500 |
| TruGroove wall, Dir/Ind, Asym. MesoOptics Lens/Asym. Performance Lens, 3500lm/4ft, 80 CRI, 4000K 2926LADWW | 35.1 | 3500 | 4000 |
| TruGroove wall, Ind/Dir, Asym. MesoOptics Lens/Asym. Performance Lens, 3500lm/4ft, 80 CRI, 3000K 2925LCDWW | 28.5 | 3500 | 3000 |
| TruGroove wall, Ind/Dir, Asym. MesoOptics Lens/Asym. Performance Lens, 3500lm/4ft, 80 CRI, 3500K 2925LBDWW | 28.5 | 3500 | 3500 |
| TruGroove wall, Ind/Dir, Asym. MesoOptics Lens/Asym. Performance Lens, 3500lm/4ft, 80 CRI, 4000K 2925LADWW | 28.6 | 3500 | 4000 |
| TruGroove wall, Ind/Dir, Asym. MesoOptics Lens/Asym. Performance Lens, 5200lm/4ft, 80 CRI, 3000K 2925LCBWW | 46.4 | 5200 | 3000 |
| TruGroove wall, Ind/Dir, Asym. MesoOptics Lens/Asym. Performance Lens, 5200lm/4ft, 80 CRI, 3500K 2925LBBWW | 46.4 | 5200 | 3500 |
| TruGroove wall, Ind/Dir, Asym. MesoOptics Lens/Asym. Performance Lens, 5200lm/4ft, 80 CRI, 4000K 2925LABWW | 46.6 | 5200 | 4000 |
| TruGroove wall, Ind/Dir, Asym. MesoOptics Lens/Asym. Performance Lens, 4600lm/4ft, 80 CRI, 3000K 2925LCCWW | 40.8 | 4600 | 3000 |
| TruGroove wall, Ind/Dir, Asym. MesoOptics Lens/Asym. Performance Lens, 4600lm/4ft, 80 CRI, 3500K 2925LBCWW | 40.9 | 4600 | 3500 |
| TruGroove wall, Ind/Dir, Asym. MesoOptics Lens/Asym. Performance Lens, 4600lm/4ft, 80 CRI, 4000K 2925LACWW | 41.1 | 4600 | 4000 |
Product family information
TruGroove LED is driving performance beyond the edge. Innovative optics deliver exceptional uniformity and wide row spacing from a 3†aperture continuous line-of light. An extended family and refined design are perfect for lighting any professional space.
Benefits
- Elevated performance to a whole new level in narrow aperture lighting
- Wide row spacing with fewer fixtures and less energy consumption
- Ideal for a variety of applications with multiple distributions and modules
Features
- MesoOptics DX and innovative optics producing optimal batwing distribution
- Symmetric, asymmetric, direct, indirect, direct/indirect and indirect/direct distribution options
- Response Daylight and Actilume Occupancy with field-enabled Daylight sensors
- Multiple lumen package and color temparature options
- Suspended, wall and surface mount versions
Applications
- Office
- Hospitality
- Banks
- Fashion
